The Whole Body Advanced CPR Manikin – Style 550 (Male / Female) is a high-fidelity resuscitation training system upgraded from model A40212, designed for advanced CPR education, tracheal intubation, and defibrillation training. The system integrates a full-body manikin with a large color LCD computer monitor, providing real-time visual feedback, guidance, and assessment.

Featuring clearly defined anatomical landmarks, realistic tactile response, and lifelike skin color, the manikin delivers immersive, standards-aligned training. It simulates essential vital signs, including pupil changes (one dilated, one contracted for contrast observation) and a palpable carotid artery pulse, supporting complete patient assessment. The airway opens correctly for ventilation, and the torso supports artificial breathing and external cardiac compressions.

The integrated CPR instrument system electronically monitors compression site, compression depth, and ventilation volume, providing immediate, color-coded indicators and voice prompts to guide learners through correct technique and timing. Training parameters—such as rate, cycles, and operating time—are configurable for instruction and assessment.

Beyond CPR, the Style 550 supports endotracheal intubation training, allowing instruction and practice with attention to insertion depth, angle, and applied pressure. The model also supports defibrillation training with realistic chest skin, enabling safe, procedural practice in advanced life support scenarios.

Available in male or female versions, the Style 550 is ideal for hospitals, medical colleges, CPR training organizations, and simulation centers requiring comprehensive, feedback-driven training.

CPR Manikin Features

• Full-body adult manikin (male or female)

• Realistic anatomy, lifelike skin tone, vivid appearance

• Vital signs simulation:

  • Pupil response (one dilated, one contracted)

  • Carotid artery pulse

• Open airway for proper positioning

• Supports artificial ventilation and external cardiac compression

CPR Instrument (Electronic Feedback) Features

• Compression site monitoring

• Ventilation (Inflation Volume) Indicators:

  • Correct: 800–1200 ml → Green

  • Insufficient → Yellow

  • Excessive → Red

• Compression Depth Indicators:

  • Correct: 4–5 cm → Green

  • Insufficient → Yellow

• Voice prompts for guided training

• Operation rate: ≥100 compressions/min

• Operation cycle: 30 compressions : 2 ventilations, 5 cycles

• Adjustable operating time (seconds)

Advanced Functions

• Tracheal Intubation: Instruction and practice of endotracheal intubation with control of depth, angle, and pressure

• Defibrillation Training: Realistic chest skin for AED/defibrillation practice

• Large Color LCD Monitor: Real-time display of training data and feedback

Areas of Use

• Hospitals and emergency medicine training

• Medical and nursing schools

• CPR/BLS/ACLS training centers

• Simulation labs and competency assessment programs

Technical Specifications

• Model Type: Whole body advanced CPR manikin

• Versions: Male / Female

• Feedback: Electronic indicators + voice prompts + LCD display

• Compression Depth Target: 4–5 cm

• Ventilation Volume Target: 800–1200 ml

• Compression Rate: ≥100/min

Safety Warnings

• For educational and training purposes only

• Not intended for clinical diagnosis or patient care

• Use under qualified instructor supervision

Storage Conditions

• Store in a clean, dry environment

• Avoid direct sunlight and excessive heat

• Clean and dry after each training session per institutional protocols

Usage Notes

• Suitable for advanced CPR and airway management curricula

• Regular inspection of sensors, airway components, and monitor connections is recommended

The Whole Body Advanced CPR Manikin – Style 550 (Male / Female) delivers high-fidelity, feedback-rich training across CPR, intubation, and defibrillation, supporting advanced, standards-aligned life support education.
